OPTICAL SMOKE ALARM KIDDE KF20NDC
Product code
7161559
Optical smoke alarm powered by mains electricity that can be interconnected with up to 23 other Kidde alarms (ionization, optical, or heat). When connected, a hazard detected by any single device triggers an alarm in all connected alarms.
If no backbox is present at the installation site, the SMK 23 or SMK 23R mounting base is required.
Features
- Interconnect capability allows up to 23 mains-powered Kidde and Firex alarms to be linked—all alarms sound simultaneously if a hazard is detected
- Alarm memory identifies the source unit within the interconnected network
- Dust compensation and insect screen reduce false alarms
- Test/silence button enables regular testing of the alarm function and can be used for temporary silencing of fault alarms
- Automatic reset after activation
- Child-resistant lock prevents unauthorized removal without tools
- Operates on mains electricity or the included 9V alkaline backup battery
Product details
Technical specifications
Product class (ETIM)Fire detector (EC001763)
Operating principleOptical
Smoke switcherno
With orientation lightingyes
Type of test-/pause buttonCombination
Mounting methodSurface mounting
Self-adhesiveno
Separate socket neededyes
Suitable for duct mountingno
Cable entryBottom side
Standaloneno
Networkable via cableyes
Networkable via radiografic (standard)no
Networkable via radio (optional)no
Max. number networkable23
Current supply primaryMains power supply
Product codes
SAPCZG825
STK7161559
PLC7161559
GTIN/EAN047871311675
Manufacturer part numberKF20NDC
Vendor material numberKF20NDC
Basic information
Package measurements (L x W x H)135 x 140 x 63 mm
Package volume1.191 l
Package weight0.36 kg
Base uniteach
Package units1 / 6 / 576
Package contents–
UNSPSC32101519
BrandKIDDE
VendorKGS FIRE & SECURITY SUOMI OY
