DOWNLIGHT DL SURFACE IP65 DL SF IP65 DN90 15W/840 36D WT
Product code
4136172
LEDVANCE Downlight Surface - downlight is an ideal solution for various enclosed outdoor areas or dusty environments. The luminaires are equipped with a 3-pin spring terminal and can be chained together. The luminaires are made of durable aluminum, the reflector is made of polycarbonate and protected by glass. Thanks to low glare (UGR below 19), it is easy to achieve glare-free lighting. LEDVANCE Downlight Surface luminaires are suitable for use at temperatures from -30 °C to +40 °C, they are rated IP65 and IK06, and have also been granted ENEC certification. The average service life of the luminaires is 100,000 hours (L70/B50 @ +25 °C), and the entire product family is covered by a five-year product warranty. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Downlight/spot/floodlight (EC001744)
Suitable for surface mountingyes
Suitable for built-in mountingno
Suitable for wall mountingyes
Suitable for suspended mountingno
Suitable for ceiling mountingyes
Suitable for pedestal/floor mountingno
Suitable for light-track mountingno
Suitable for clamp-mountingno
Suitable for low voltage cable systemno
AdjustabilityNot adjustable
With movement sensorno
With light sensorno
Lamp typeLED not exchangeable
With light sourceyes
Suitable for number of light sources0
Product codes
SAPCZB925
STK4136172
PLC4136172
GTIN/EAN4058075768871
Manufacturer part number4058075768871
Vendor material number4136172
Basic information
Package measurements (L x W x H)117 x 117 x 147 mm
Package volume2.012 l
Package weight0.7 kg
Base uniteach
Package units1 / 18 / 162 / 324
Package contents–
UNSPSC39111544
BrandLEDVANCE
VendorLEDVANCE OY
Documents (3)
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)9.1
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000490
Manufacturer
NameLEDVANCE GmbH
Websitewww.ledvance.com/contact
Postal addressParkring 1-5, 85748, Garching near Munich, Germany
