SEALED INDUSTRIAL LUMINAIRE DP MAX 1200 27W/840 IP69

Product code
4325388
DAMP PROOF MAX - durable enclosed industrial luminaires guarantee durability in challenging conditions. The PMMA housing and PA66 end caps are protected against UV radiation, making the luminaires suitable for outdoor use. The product offers comprehensive project-specific customization options through the LEDVANCE Project Team. Key technical specifications: • Luminous flux: 4000 lm • Color temperature: 4000 K, CRI80 • Power: 27 W • Luminous efficacy: 148 lm/W • Beam angle: 120 D • Dimmable: No • Dimensions (Length/Width/Height): 1450 x 125 x 138 mm • Ingress protection rating: IP69 and IK10 • Luminaire material: Housing: PMMA; End caps: PA66 • Average service life: 100,000 hours (L70/B50 +25 C) • Average service life: 100,000 hours (L80/B10 +25 C) • Operating temperature range: -40…+50 C • Warranty: 5 years • Certifications: CE, ENEC, D-marking Most common applications: Factories, food industry, car wash halls This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Ceiling-/wall luminaire (EC002892)
Suitable for wall mountingyes
Suitable for suspended mountingyes
Suitable for ceiling mountingyes
Suitable for built-in mountingno
Suitable for surface mountingyes
Suitable for light line configurationno
Suitable for clamp-mountingno
Suitable for workplace according to EN 12464-1no
Lamp typeLED not exchangeable
With light sourceyes
Suitable for number of light sources0
Housing materialPlastic
Surface protection housingUntreated
Housing colourGrey
Material coverPlastic, opal

Product codes

SAPDKR581
STK4325388
PLC4325388
GTIN/EAN4058075849808
Manufacturer part number4058075849808
Vendor material number4325388

Basic information

Package measurements (L x W x H)1581 x 165 x 146 mm
Package volume38.086 l
Package weight5.585 kg
Base uniteach
Package units1 / 4 / 28
Package contents
UNSPSC39111544
BrandLEDVANCE
VendorLEDVANCE OY

Environment and safety

Carbon footprint data

Carbon footprint of product manufacturing (A1–A3 GWP value)173.135
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000001043

Manufacturer

NameLEDVANCE GmbH
Postal addressParkring 1-5, 85748, Garching near Munich, Germany
