SEALED INDUSTRIAL LUMINAIRE DP MAX 1500 38W/840 IP69
Product code
4325390
DAMP PROOF MAX - durable enclosed industrial luminaires guarantee durability in challenging conditions. The PMMA housing and PA66 end caps are protected against UV radiation, making the luminaires suitable for outdoor use. The product offers comprehensive project-specific customization options through the LEDVANCE Project Team.
Key technical specifications:
• Luminous flux: 6000 lm
• Color temperature: 4000 K, CRI80
• Power: 38 W
• Luminous efficacy: 158 lm/W
• Beam angle: 120 D
• Dimmable: No
• Dimensions (Length/Width/Height): 1730 x 125 x 138 mm
• Ingress protection rating: IP69 and IK10
• Luminaire material: Housing: PMMA; End caps: PA66
• Average service life: 100,000 hours (L70/B50 +25 C)
• Average service life: 100,000 hours (L80/B10 +25 C)
• Operating temperature range: -40…+50 C
• Warranty: 5 years
• Certifications: CE, ENEC, D-mark
Common applications: Factories, food industry, car wash halls This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Ceiling-/wall luminaire (EC002892)
Suitable for wall mountingyes
Suitable for suspended mountingyes
Suitable for ceiling mountingyes
Suitable for built-in mountingno
Suitable for surface mountingyes
Suitable for light line configurationno
Suitable for clamp-mountingno
Suitable for workplace according to EN 12464-1no
Lamp typeLED not exchangeable
With light sourceyes
Suitable for number of light sources0
Housing materialPlastic
Surface protection housingUntreated
Housing colourGrey
Material coverPlastic, opal
Product codes
SAPDKR579
STK4325390
PLC4325390
GTIN/EAN4058075849822
Manufacturer part number4058075849822
Vendor material number4325390
Basic information
Package measurements (L x W x H)1861 x 165 x 146 mm
Package volume44.831 l
Package weight6.544 kg
Base uniteach
Package units1 / 4 / 28
Package contents–
UNSPSC39111544
BrandLEDVANCE
VendorLEDVANCE OY
Documents (6)
Images
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)202.864
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000001043
Manufacturer
NameLEDVANCE GmbH
Websitewww.ledvance.com/contact
Postal addressParkring 1-5, 85748, Garching near Munich, Germany
