SOCKET OUTLET MONO-1 USB-OUTLET, KUPARI

MONO-1 USB is an ultra-low-profile socket (minimum surface thickness of 20 mm) designed for installation into tabletops, shelves, furniture, etc. Thanks to its low profile and plug-in power connection, it can also be used in freestanding furniture such as tables, sofas, and bookshelves. MONO-1 USB features two USB ports (USB-A and USB-C). When closed, the surface of the MONO socket is flush, ensuring the tabletop appears smooth and uniform. Thanks to the protective cover design, the socket is also protected against splashing water (IP54) when closed. MONO-1 USB sockets are simple and quick to install. The socket must be installed into a surface with a minimum material thickness of 15 mm. There is no upper limit for wooden surfaces, but for stone or glass surfaces, the material thickness must be between 15 mm and 20 mm. A hole matching the installation instructions is drilled into the tabletop or, for example, the side of an island, into which the socket is tightened from above using integrated fasteners. Mounting is easily performed from the surface top, and all fasteners and mounting screws remain neatly hidden. The supplied power cord is connected to the MONO socket, and the other end is plugged into a grounded outlet. For easier installation and cable passage, the plug is supplied separately and attached at the installation site. If the socket to which MONO is connected is protected by a 10 A fuse, then 10 A is also the maximum load for MONO. Similarly, for a 16 A connection, the maximum load for MONO is 16 A. The power output of the USB model is distributed between the USB-A and USB-C ports according to usage: 5 V / 2.4 A, with a maximum total power of 12 W. The standby power consumption of the USB ports in MONO sockets is <0.1 W. This product description is an automated translation of the original Finnish description.
