PHASE-INDICATOR 5P 63A 400V IP44
Product code
2425163
The three-phase tester allows quick and reliable testing of three-phase circuits. With the tester, you can see the phase rotation and whether there is current in all phases. Compliant with standard VDE 0413, part 7, DIN-EN 61557-7. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Phase sequence indicator (EC001189)
IndicationLED
Indication three phasesyes
Frequency50 - 60 Hz
Voltage230 - 400 V
Motor rotation direction testeryes
Contactless detection of the sense of rotationyes
Product codes
SAPDHI750
STK2425163
PLC2425163
GTIN/EAN4015394010791
Manufacturer part number1437
Vendor material number1437
Basic information
Package measurements (L x W x H)220 x 100 x 100 mm
Package volume2.2 l
Package weight0.7 kg
Base uniteach
Package units1 / 5
Package contents–
UNSPSC39121402
BrandMENNEKES
VendorMENNEKES ELEKTROTECHNIK GMBH
