PHASE INVENTER INLET 2511 16A5P 6H400V - IP44
Product code
2424707
Surface-mounted junction box 16A 5P 400V. Enclosure size 100x75 mm. Junction box with phase switch. Screw terminals. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)CEE appliance inlet (IEC 60309) (EC001319)
IEC-amperage16 A
Amperage according to UL/CSA (for UL-version)20 A
Voltage according to EN 60309-2400 V (50+60 Hz) red
Rated voltage399 - 400 V
Rated frequency50 - 60 Hz
Number of poles5
Clock hour position6 h
Identification colourRed
RAL-number3013
Degree of protection (IP)IP44
Connection systemScrewed terminal
Construction typeSurface mounted device plug
Phase inverteryes
Insert directionRight-angled
MaterialPlastic
Product codes
SAPABV258
STK2424707
PLC2424707
GTIN/EAN4015394015352
Manufacturer part number2511
Vendor material number2511
Basic information
Package measurements (L x W x H)0 x 0 x 0 mm
Package volume1.267 l
Package weight0.275 kg
Base uniteach
Package units10
Package contents–
UNSPSC39121402
BrandMENNEKES
VendorMENNEKES ELEKTROTECHNIK GMBH
Documents (5)
Brochures & documents
Links
Environment and safety
Manufacturer
NameMENNEKES Elektrotechnik GmbH & Co. KG
Websitehttps://www.mennekes.org/
Postal addressAloys-Mennekes-Straße 1, D-57399 KIRCHHUNDEM
