Phase inverter Mennekes ProTOP 3319A 16A5p6h
Product code
2425139
Step switch: Power plug with step switch 16A 5-pole 6h 400V. Screw terminals suitable for 2.5-6 mm2 wires. With adjustable pull-off collar.
This product description is an automated translation of the original Finnish description.Product details
Technical specifications
Product class (ETIM)CEE plug (IEC 60309) (EC000140)
IEC-amperage16 A
Amperage according to UL/CSA (for UL-version)20 A
Number of poles5
Voltage according to EN 60309-2400 V (50+60 Hz) red
Clock hour position6 h
Identification colourRed
RAL-number3013
Phase inverteryes
Degree of protection (IP)IP44
Connection systemScrewed terminal
Cable entryGland nut
Insert directionStraight
MaterialPlastic
Contact materialCuZn
Surface treatment contactsUntreated
Product codes
SAPCNH607
STK2425139
PLC2425139
GTIN/EAN4015394201182
Manufacturer part number3319A
Vendor material number3319A
Basic information
Package measurements (L x W x H)160 x 70 x 65 mm
Package volume0.728 l
Package weight0.16 kg
Base uniteach
Package units1 / 10 / 1520
Package contents–
UNSPSC39121402
BrandMENNEKES
VendorMENNEKES ELEKTROTECHNIK GMBH
Documents (3)
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)1.4442
GWP, uniteach
Source for GWP dataEandoX
Responsible party
NameMENNEKES Elektrotechnik GmbH & Co. KG
Websitehttps://www.mennekes.org/
Postal addressAloys-Mennekes-Straße 1, D-57399 KIRCHHUNDEM
