PHASE INVERTER PROTOP 3322 32A5P6H 400V
Product code
2425137
Step switch: Power plug with step switch, 32A 5-pole 6h 400V. Screw terminals suitable for 2.5-6 mm² wires. With adjustable strain relief clamp.
This product description is an automated translation of the original Finnish description.Product details
Technical specifications
Product class (ETIM)CEE plug (IEC 60309) (EC000140)
IEC-amperage32 A
Amperage according to UL/CSA (for UL-version)30 A
Number of poles5
Voltage according to EN 60309-2380-415 V (50+60 Hz) red
Clock hour position6 h
Identification colourRed
RAL-number3013
Phase inverteryes
Degree of protection (IP)IP44
Connection systemScrewed terminal
Cable entryAnti-kink sleeve
Insert directionStraight
MaterialPlastic
Contact materialCuSn
Surface treatment contactsUntreated
Product codes
SAPCNB216
STK2425137
PLC2425137
GTIN/EAN4015394215530
Manufacturer part number3322
Vendor material number3322
Basic information
Package measurements (L x W x H)200 x 90 x 75 mm
Package volume1.35 l
Package weight0.3 kg
Base uniteach
Package units1 / 10 / 660
Package contents–
UNSPSC39121402
BrandMENNEKES
VendorMENNEKES ELEKTROTECHNIK GMBH
