POWER CONNECTOR 14112 63A5P6H400V IP44
Product code
2425101
Power extension socket 63A 5P 400V. X-contact contact sleeve technology. Screw connections. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)CEE coupling (IEC 60309) (EC001320)
IEC-amperage63 A
Amperage according to UL/CSA (for UL-version)60 A
Number of poles5
Voltage according to EN 60309-2230 V (50+60 Hz) blue
Clock hour position6 h
Identification colourRed
RAL-number3013
Degree of protection (IP)IP44
Connection systemScrewed terminal
Insert directionStraight
Cable entryGland nut
MaterialPlastic
Contact materialCuZn
Surface treatment contactsUntreated
Military modelno
Product codes
SAPAEV780
STK2425101
PLC2425101
GTIN/EAN4015394238164
Manufacturer part number14112
Vendor material number14112
Basic information
Package measurements (L x W x H)265 x 110 x 95 mm
Package volume2.769 l
Package weight0.865 kg
Base uniteach
Package units1 / 5 / 225
Package contents–
UNSPSC39121308
BrandMENNEKES
VendorMENNEKES ELEKTROTECHNIK GMBH
