POWER CONNECTOR 14225 125A5P6H400V IP67
Product code
2425105
Extension socket 125A 5P 400V. The extension socket features X-contact contact sleeve technology. The extension socket has a rubber grip area that facilitates use in harsh conditions. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)CEE coupling (IEC 60309) (EC001320)
IEC-amperage125 A
Amperage according to UL/CSA (for UL-version)100 A
Number of poles5
Voltage according to EN 60309-2400 V (50+60 Hz) red
Clock hour position6 h
Identification colourRed
RAL-number3013
Degree of protection (IP)IP67
Connection systemScrewed terminal
Insert directionStraight
Cable entryGland nut
MaterialPlastic
Contact materialCuZn
Surface treatment contactsUntreated
Military modelno
Product codes
SAPAEV784
STK2425105
PLC2425105
GTIN/EAN4015394240815
Manufacturer part number14225
Vendor material number14225
Basic information
Package measurements (L x W x H)305 x 80 x 115 mm
Package volume2.806 l
Package weight1.6 kg
Base uniteach
Package units1 / 5 / 10 / 160
Package contents–
UNSPSC39121308
BrandMENNEKES
VendorMENNEKES ELEKTROTECHNIK GMBH
Documents (4)
Brochures & documents
Links
Environment and safety
Manufacturer
NameMENNEKES Elektrotechnik GmbH & Co. KG
Websitehttps://www.mennekes.org/
Postal addressAloys-Mennekes-Straße 1, D-57399 KIRCHHUNDEM
