POWER PLUG 13212 63A5P6H400V IP67
Product code
2425102
Power plug 63A 5P 400V. Product from the PowerTOP Xtra R series with nickel-plated contacts. Screw connections. The rubber grip area in the plug facilitates use in difficult conditions. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)CEE plug (IEC 60309) (EC000140)
IEC-amperage63 A
Amperage according to UL/CSA (for UL-version)60 A
Number of poles5
Voltage according to EN 60309-2400 V (50+60 Hz) red
Clock hour position6 h
Identification colourRed
RAL-number3013
Phase inverterno
Degree of protection (IP)IP67
Connection systemScrewed terminal
Cable entryGland nut
Insert directionStraight
MaterialPlastic
Contact materialCuZn
Surface treatment contactsNickel-plated
Product codes
SAPAEV781
STK2425102
PLC2425102
GTIN/EAN4015394238829
Manufacturer part number13212
Vendor material number13212
Basic information
Package measurements (L x W x H)255 x 115 x 115 mm
Package volume3.372 l
Package weight1.52 kg
Base uniteach
Package units1 / 5 / 10 / 225
Package contents–
UNSPSC39121402
BrandMENNEKES
VendorMENNEKES ELEKTROTECHNIK GMBH
