POWER PLUG POWERTOPXTRA 13516 32A4P6H400V IP54
Product code
2425149
PISTOTULPPA POWERTOP® XTRA ERGOCONTACT® 13516. Regardless of the version or application, the PowerTOP® Xtra plug ensures proven success factors: ergonomic design, easy installation, safe and seamless connection.
The PowerTOP® Xtra plug meets IP54 protection class requirements, providing protection not only against splashing water but also exceptionally well against dust.
Features- Screw connection technology ErgoCONTACT®
- ergonomic housing design with contoured grip areas
- rubberized cable entry with seal
- strain relief and twist protection
- rotary lock and safety latch
- space for self-adhesive labels
- the future speaks PowerTOP® Xtra language: PowerTOP® Xtra plug replaces ProTOP plug 152A
Redesigned power plug. Available in screw connection and quick-connect versions. High-quality and durable product. Screw connectors ErgoCONTACT®.
This product description is an automated translation of the original Finnish description.Product details
Technical specifications
Product class (ETIM)CEE plug (IEC 60309) (EC000140)
IEC-amperage32 A
Amperage according to UL/CSA (for UL-version)30 A
Number of poles4
Voltage according to EN 60309-2400 V (50+60 Hz) red
Clock hour position6 h
Identification colourRed
RAL-number3013
Phase inverterno
Degree of protection (IP)IP54
Connection systemScrewed terminal
Cable entryGland nut
Insert directionStraight
MaterialPlastic
Contact materialCuZn
Surface treatment contactsUntreated
Product codes
SAPCXY664
STK2425149
PLC2425149
GTIN/EAN4015394296737
Manufacturer part number13516
Vendor material number13516
Basic information
Package measurements (L x W x H)170 x 70 x 70 mm
Package volume0.833 l
Package weight0.35 kg
Base uniteach
Package units1 / 10
Package contents–
UNSPSC39121402
BrandMENNEKES
VendorMENNEKES ELEKTROTECHNIK GMBH
Documents (7)
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)2.4731
GWP, uniteach
Source for GWP dataEandoX
Responsible party
NameMENNEKES Elektrotechnik GmbH & Co. KG
Websitehttps://www.mennekes.org/
Postal addressAloys-Mennekes-Straße 1, D-57399 KIRCHHUNDEM
