POWER PLUG POWERTOPXTRA 13564 - 16A5P 7H500V - IP54
Product code
2425132
PowerTOP® Xtra R - with ErgoCONTACT® screw connection - heat-resistant and nickel-plated contacts - 500 V. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)CEE plug (IEC 60309) (EC000140)
IEC-amperage16 A
Number of poles5
Voltage according to EN 60309-2500 V (50+60 Hz) black
Clock hour position7 h
Identification colourBlack
Phase inverterno
Degree of protection (IP)IP54
Connection systemScrewed terminal
Cable entryGland nut
Insert directionStraight
MaterialPlastic
Surface treatment contactsNickel-plated
Military modelno
Product codes
SAPCMT616
STK2425132
PLC2425132
GTIN/EAN4015394293842
Manufacturer part number13564
Vendor material number13564
Basic information
Package measurements (L x W x H)163 x 74 x 68 mm
Package volume0.82 l
Package weight0.195 kg
Base uniteach
Package units1 / 10 / 1120
Package contents–
UNSPSC39121402
BrandMENNEKES
VendorMENNEKES ELEKTROTECHNIK GMBH
Documents (5)
Brochures & documents
Links
Environment and safety
Manufacturer
NameMENNEKES Elektrotechnik GmbH & Co. KG
Websitehttps://www.mennekes.org/
Postal addressAloys-Mennekes-Straße 1, D-57399 KIRCHHUNDEM
