POWER PLUG POWERTOPXTRA 13643 16A5P6H400V R IP67/IP69

Product code
2425177

PowerTOP® Xtra power plug. Robust technology for demanding environmental conditions. PowerTOP® Xtra plugs make an impression with their features: ergonomic design, easy installation, safe and quick connection.

The plugs in the PowerTOP® Xtra product family meet protection class IP67/IP69, providing protection not only against temporary immersion but also against high-pressure washing.

Features
  • Screw connection technology ErgoCONTACT®
  • Ergonomic housing design with contoured grip areas
  • Exceptionally heat-resistant contact carrier
  • Nickel-plated contacts
  • Rubberized cable entry with seal
  • Rubberized bayonet ring
  • Protected against dust and temporary immersion
  • Protected against high-pressure cleaning
  • Strain relief and twist protection
  • Twist lock and safety latch
  • Space for self-adhesive labels
This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)CEE plug (IEC 60309) (EC000140)
IEC-amperage16 A
Amperage according to UL/CSA (for UL-version)20 A
Number of poles5
Voltage according to EN 60309-2400 V (50+60 Hz) red
Clock hour position6 h
Identification colourRed
RAL-number3013
Phase inverterno
Degree of protection (IP)IP67
Connection systemScrewed terminal
Cable entryGland nut
Insert directionStraight
MaterialPlastic
Contact materialCuSn
Surface treatment contactsNickel-plated

Product codes

SAPDIS696
STK2425177
PLC2425177
GTIN/EAN4015394305958
Manufacturer part number13643
Vendor material number13643

Basic information

Package measurements (L x W x H)0 x 0 x 0 mm
Package volume0.083 l
Package weight0.03 kg
Base uniteach
Package units10 / 100 / 1120
Package contents
UNSPSC39121402
BrandMENNEKES
VendorMENNEKES ELEKTROTECHNIK GMBH

Environment and safety

Manufacturer

NameMENNEKES Elektrotechnik GmbH & Co. KG
Postal addressAloys-Mennekes-Straße 1, D-57399 KIRCHHUNDEM
