POWER PLUG POWERTOPXTRA 13660 32A5P6H400V R IP67/ IP69
Product code
2425173
PowerTOP Xtra power plug Robust technology for demanding environmental conditions. PowerTOP Xtra plugs make an impression with their features: ergonomic design, easy installation, safe and rapid connection. The plugs in the PowerTOP Xtra product family meet protection class IP67/IP69, so they are protected not only against temporary immersion but also against high-pressure washing. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)CEE plug (IEC 60309) (EC000140)
IEC-amperage32 A
Amperage according to UL/CSA (for UL-version)30 A
Number of poles5
Voltage according to EN 60309-2400 V (50+60 Hz) red
Clock hour position6 h
Identification colourRed
RAL-number3013
Phase inverterno
Degree of protection (IP)IP67
Connection systemScrewed terminal
Cable entryGland nut
Insert directionStraight
MaterialPlastic
Contact materialCuSn
Surface treatment contactsNickel-plated
Product codes
SAPDIK754
STK2425173
PLC2425173
GTIN/EAN4015394306009
Manufacturer part number13660
Vendor material number13660
Basic information
Package measurements (L x W x H)200 x 97 x 97 mm
Package volume1.882 l
Package weight0.42 kg
Base uniteach
Package units1 / 10 / 10 / 540
Package contents–
UNSPSC39121402
BrandMENNEKES
VendorMENNEKES ELEKTROTECHNIK GMBH
Documents (6)
Brochures & documents
Links
Environment and safety
Manufacturer
NameMENNEKES Elektrotechnik GmbH & Co. KG
Websitehttps://www.mennekes.org/
Postal addressAloys-Mennekes-Straße 1, D-57399 KIRCHHUNDEM
