POWER PLUG POWERTOPXTRA 16A3P 6H230V - IP54
Product code
2425120
One product family for all applications – the PowerTOP® Xtra product family now also covers 16 A currents. New 16 A variants for professional to professional:
- 3 P plugs and extension sockets
- 5 P plugs and extension sockets for different voltages
- 5 P plugs and extension sockets with heat-resistant and nickel-plated contacts
Regardless of configuration and application area, all PowerTOP® Xtra plugs impress with proven and tested features: ergonomic design, ease of installation, safe and easy connection, and X-CONTACT® inside. Thanks to innovative contact pins, connecting and disconnecting is light and effortless. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)CEE plug (IEC 60309) (EC000140)
IEC-amperage16 A
Amperage according to UL/CSA (for UL-version)20 A
Number of poles3
Voltage according to EN 60309-2230 V (50+60 Hz) blue
Clock hour position6 h
Identification colourBlue
RAL-number5007
Phase inverterno
Degree of protection (IP)IP54
Connection systemScrewed terminal
Cable entryGland nut
Insert directionStraight
MaterialPlastic
Contact materialCuZn
Surface treatment contactsUntreated
Product codes
SAPCMI096
STK2425120
PLC2425120
GTIN/EAN4015394291817
Manufacturer part number13502
Vendor material number13502
Basic information
Package measurements (L x W x H)165 x 35 x 40 mm
Package volume0.231 l
Package weight0.16 kg
Base uniteach
Package units1 / 10 / 1120
Package contents–
UNSPSC39121402
BrandMENNEKES
VendorMENNEKES ELEKTROTECHNIK GMBH
Documents (5)
Brochures & documents
Links
Environment and safety
Manufacturer
NameMENNEKES Elektrotechnik GmbH & Co. KG
Websitehttps://www.mennekes.org/
Postal addressAloys-Mennekes-Straße 1, D-57399 KIRCHHUNDEM
