POWER SOCKET-OUTLET 16A5P6H400V IP69 DUOI 5612506G

Product code
2425166
Better safe than sorry—the DUOi surface-mounted socket makes an impression with its exceptionally secure DUO locking mechanism. This prevents the plug from being disconnected under load, and when DUOi is switched off, it can additionally be secured with a Lockout-Tagout padlock. Equipped with IP69 protection, the DUOi surface-mounted socket is protected against the ingress of foreign substances and splashing water. A clearly visible LED light glows green when powered on and turns off if the power supply is interrupted. A smart solution for numerous applications. Machinery and equipment operate around the clock, conveyor belts rotate, and cranes load tons of material: this happens continuously in container terminals and shipyards, in heavy industry, mining, and the food industry. Electrical supply must be safe and reliable to ensure smooth and cost-efficient operation. This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)CEE socket outlet (IEC 60309) (EC001321)
Mounting methodSurface mounted
IEC-amperage16 A
Number of poles5
Voltage according to EN 60309-2400 V (50+60 Hz) red
Clock hour position6 h
Identification colourRed
Housing colourWhite
Degree of protection (IP)IP68
Connection systemScrewed terminal
Cable entryAnti-kink sleeve
MaterialPlastic
Type of fasteningInner lying mounting
Insulated mountingyes
Lockableyes
Text fieldno

Product codes

SAPDII767
STK2425166
PLC2425166
GTIN/EAN4015394304029
Manufacturer part number5612506G
Vendor material number5612506G

Basic information

Package measurements (L x W x H)230 x 150 x 120 mm
Package volume4.14 l
Package weight1.2 kg
Base uniteach
Package units1
Package contents
UNSPSC39121308
BrandMENNEKES
VendorMENNEKES ELEKTROTECHNIK GMBH

Environment and safety

Manufacturer

NameMENNEKES Elektrotechnik GmbH & Co. KG
Postal addressAloys-Mennekes-Straße 1, D-57399 KIRCHHUNDEM
