POWER SOCKET-OUTLET 32A5P6H400V IP67 DUOI 5614506G
Product code
2425169
DUOi surface-mounted socket: A smart solution for numerous applications
Equipment and machinery operate around the clock, conveyor belts rotate, and cranes load tons of material: this happens continuously in container terminals and shipyards, in heavy industry, mining, and the food industry.
Electrical power supply must be safe and reliable to ensure smooth and cost-efficient operation. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)CEE socket outlet (IEC 60309) (EC001321)
Mounting methodSurface mounted
IEC-amperage32 A
Number of poles5
Voltage according to EN 60309-2400 V (50+60 Hz) red
Clock hour position6 h
Identification colourRed
Housing colourWhite
Degree of protection (IP)IP68
Connection systemScrewed terminal
Cable entryGland nut
MaterialPlastic
Type of fasteningInner lying mounting
Insulated mountingyes
Lockableyes
Text fieldno
Product codes
SAPDII770
STK2425169
PLC2425169
GTIN/EAN4015394303114
Manufacturer part number5614506G
Vendor material number5614506G
Basic information
Package measurements (L x W x H)230 x 150 x 200 mm
Package volume6.9 l
Package weight1.2 kg
Base uniteach
Package units1
Package contents–
UNSPSC39121308
BrandMENNEKES
VendorMENNEKES ELEKTROTECHNIK GMBH
