WALL MOUNTED RECEPTACLE 1649 DOUPLEBOX IP44
Product code
2423771
Combined box
Power outlet box containing one 16A 5P power outlet and additionally one 16A Schuko outlet in the box.
This product description is an automated translation of the original Finnish description.Product details
Technical specifications
Product class (ETIM)CEE socket outlet combination (IEC 60309) (EC000379)
CEE socket outlet 16 A1x16A5p400V
CEE socket outlet 32 ANone
CEE socket outlet 63 ANone
CEE socket outlet 125 ANone
Number of socket outlets with protective contact CEE 7/3 (type F)1
Earth leakage switchNone
Housing materialPlastic
Power supply/connection possibility1 cable (branch line)
HandlingWall mounting
Degree of protection (IP)IP44
Military modelno
ColourGrey
Height150 mm
Width82 mm
Depth140 mm
Product codes
SAPABV309
STK2423771
PLC2423771
GTIN/EAN4015394020035
Manufacturer part number1649
Vendor material number1649
Basic information
Package measurements (L x W x H)150 x 83 x 139 mm
Package volume1.731 l
Package weight0.396 kg
Base uniteach
Package units1 / 5 / 55 / 330
Package contents–
UNSPSC39121308
BrandMENNEKES
VendorMENNEKES ELEKTROTECHNIK GMBH
