WALL MOUNTED RECEPTACLE 27002 16A4P 6H400V IP44
Product code
2425109
Surface-mounted power socket. Four-pin 16A 400V system. Screw-terminal connections. Enclosure rating IP44. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)CEE socket outlet (IEC 60309) (EC001321)
Mounting methodSurface mounted
IEC-amperage16 A
Number of poles4
Voltage according to EN 60309-2380-415 V (50+60 Hz) red
Clock hour position6 h
Identification colourRed
Housing colourOther
Degree of protection (IP)IP44
Connection systemScrewed terminal
Cable entryGland nut
MaterialPlastic
Type of fasteningExternal mounting
Insulated mountingyes
Lockableno
Text fieldno
Product codes
SAPCHR524
STK2425109
PLC2425109
GTIN/EAN6410024251090
Manufacturer part number27002
Vendor material number2425109
Basic information
Package measurements (L x W x H)145 x 90 x 115 mm
Package volume1.501 l
Package weight0.25 kg
Base uniteach
Package units1 / 10 / 660
Package contents–
UNSPSC39121308
BrandMENNEKES
VendorMENNEKES ELEKTROTECHNIK GMBH
