WALL MOUNTED RECEPTACLE 27005 32A3P 6H230V - IP44
Product code
2424820
Surface-mounted power socket 32A 3P 230V IP44. Screw terminals. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)CEE socket outlet (IEC 60309) (EC001321)
IEC-amperage32 A
Number of poles3
Voltage according to EN 60309-2200-250 V (50+60 Hz) blue
Clock hour position6 h
Identification colourBlue
RAL-number5007
Degree of protection (IP)IP44
Connection systemScrewed terminal
MaterialPlastic
Type of fasteningExternal mounting
Insulated mountingno
Military modelno
Product codes
SAPABV304
STK2424820
PLC2424820
GTIN/EAN4015394009955
Manufacturer part number27005
Vendor material number27005
Basic information
Package measurements (L x W x H)89 x 160 x 110 mm
Package volume1.566 l
Package weight0.29 kg
Base uniteach
Package units1 / 10 / 540
Package contents–
UNSPSC39121308
BrandMENNEKES
VendorMENNEKES ELEKTROTECHNIK GMBH
Documents (4)
Brochures & documents
Links
Environment and safety
Manufacturer
NameMENNEKES Elektrotechnik GmbH & Co. KG
Websitehttps://www.mennekes.org/
Postal addressAloys-Mennekes-Straße 1, D-57399 KIRCHHUNDEM
