WALL MOUNTED RECEPTACLE 5113 63A5P 6H400V - IP67
Product code
2424843
Socket switch combination: Five-pin 63A power socket with ON/OFF switch. Screw terminal connections. The switch can be locked with a separate padlock. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)CEE socket outlet, disconnectable, with fuse (IEC 60309) (EC001324)
IEC-amperage63 A
Amperage according to UL/CSA (for UL-version)60 A
Number of poles5
Voltage according to EN 60309-2400 V (50+60 Hz) red
Clock hour position6 h
Identification colourRed
Degree of protection (IP)IP67
SwitchMechanical locking
Type of switchSpecial switch
With earth leakage switchno
Empty locations on mounting railno
Housing materialPlastic
ModelBase unit and cover
ProtectionMixed
Contact materialCuZn
Product codes
SAPABV396
STK2424843
PLC2424843
GTIN/EAN4015394025153
Manufacturer part number5113A
Vendor material number5113A
Basic information
Package measurements (L x W x H)0 x 0 x 0 mm
Package volume11.858 l
Package weight0.84 kg
Base uniteach
Package units1 / 3
Package contents–
UNSPSC39121308
BrandMENNEKES
VendorMENNEKES ELEKTROTECHNIK GMBH
Documents (5)
Brochures & documents
Links
Environment and safety
Manufacturer
NameMENNEKES Elektrotechnik GmbH & Co. KG
Websitehttps://www.mennekes.org/
Postal addressAloys-Mennekes-Straße 1, D-57399 KIRCHHUNDEM
