WALL MOUNTED RECEPTACLE 9382 32A 5P6H400V IP67
Product code
2425106
Wall mounted recept. 32A5p6h400V, IP67
Power socket box 32A 5P 400V IP67. The socket has two accessible cable entry points. Screw terminals. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)CEE socket outlet (IEC 60309) (EC001321)
IEC-amperage32 A
Amperage according to UL/CSA (for UL-version)30 A
Number of poles5
Voltage according to EN 60309-2380-415 V (50+60 Hz) red
Clock hour position6 h
Identification colourRed
RAL-number3013
Housing colourWhite
Degree of protection (IP)IP67
Connection systemScrewed terminal
Cable entryGland nut
MaterialPlastic
Contact materialCuZn
Surface treatment contactsUntreated
Type of fasteningExternal mounting
Product codes
SAPCCI224
STK2425106
PLC2425106
GTIN/EAN4015394281764
Manufacturer part number9382
Vendor material number9382
Basic information
Package measurements (L x W x H)150 x 110 x 160 mm
Package volume2.64 l
Package weight0.57 kg
Base uniteach
Package units1 / 5 / 330
Package contents–
UNSPSC39121308
BrandMENNEKES
VendorMENNEKES ELEKTROTECHNIK GMBH
