CABLE LADDER 6 M 102LS6 FE C2 EZN 200X56X6000
Product code
1474514
The LS-series light-duty shelves are a competitive option for applications that do not require high climate resistance ratings or heavy-duty shelf load capacity. The lighter, more environmentally friendly structure simplifies installation. A simple mounting system ensures quick installation and efficient use of additional accessories on site. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Cable ladder (EC000854)
Type of side joistProfile (open)
Side perforationyes
Type of rungPerforated profile
Fixation rungWelded
Height56 mm
Width200 mm
Length6000 mm
Working length6000 mm
Usable cross section6000 mm²
Suitable for circuit integrityyes
Rung centre spacing25 mm
Vertical cable ladderno
MaterialSteel
Material qualityOther
Surface protectionContinuously galvanised
Product codes
SAPCZX524
STK1474514
PLC1474514
GTIN/EAN7394333000206
Manufacturer part numberMP-102LS6
Vendor material number1474514
Basic information
Package measurements (L x W x H)1000 x 200 x 56 mm
Package volume11.2 l
Package weight1.247 kg
Base unitMeter
Package units6 / 60
Package contents–
UNSPSC39121206
BrandMP BOLAGEN
VendorMP BOLAGEN OY
Documents (5)
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)3.3544
GWP, unitMeter
Source for GWP dataEPD
