CABLE TRAY MP-340SV C2 200X45X3000 BLK
Product code
1406878
The solid painted shelf is delivered so that the inner sides of both ends have uncoated areas. Other lengths and color shades are available as needed. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Cable tray (EC000047)
Height45 mm
Width200 mm
Material thickness1 mm
Length3000 mm
Working length3000 mm
Usable cross section9000 mm²
With coverno
Side perforationno
Bottom perforationno
NATO-mounting holesno
ModelWithout connector
Type of connectionOther
Suitable for circuit integrityyes
MaterialSteel
Material qualityOther
Product codes
SAPDAN758
STK1406878
PLC1406878
GTIN/EAN7394333100814
Manufacturer part number1363302
Vendor material number1406878
Basic information
Package measurements (L x W x H)1000 x 200 x 45 mm
Package volume9 l
Package weight2.393 kg
Base unitMeter
Package units3 / 300 / 180
Package contents–
UNSPSC39131704
BrandMP BOLAGEN
VendorMP BOLAGEN OY
Documents (4)
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)6.4132
GWP, unitMeter
Source for GWP dataEPD
