CORNER PIECE MP-477SV C2 650X50X650 BLK
Product code
1467187
The L-shaped corner piece simultaneously serves as an external extension that covers the unfinished ends of cut shelves. The corner piece can be equipped with a built-in roof beam fastener upon order. Custom-sized L-shaped corner pieces can be provided as needed. (Provide measurements as seen from above.) This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Bend for cable tray (EC002400)
Change of directionHorizontal
Angle90°
Construction typeBend rigid
Bend modelSmooth bend
With coverno
Suitable for cable tray height45 mm
Suitable for cable tray width500 mm
Material thickness1 mm
Side perforationno
Bottom perforationno
ModelWithout connector
Suitable for circuit integrityyes
MaterialSteel
Stainless steel, pickledno
Material qualityOther
Product codes
SAPDAQ040
STK1467187
PLC1467187
GTIN/EAN6438100362478
Manufacturer part numberMP-477SV
Vendor material number1467187
Basic information
Package measurements (L x W x H)604 x 604 x 50 mm
Package volume18.241 l
Package weight3.5 kg
Base uniteach
Package units1 / 2
Package contents–
UNSPSC39131705
BrandMP BOLAGEN
VendorMP BOLAGEN OY
