CABLE GLAND V-TEC M12, RAL7035
Product code
1711112
Cable gland fully metric M12, PA, Light grey, 7035
Product description
O-ring seals ensure venting and sealing in distribution boxes and housings. For example, in OBO's tested O-ring seal V-TEC, the sealing surface achieves enclosure rating IP 68 thanks to OBO's special molding technology. Its venting and sealing have been tested according to DIN EN 50262. Optimal thread adaptation to the correct rise ensures excellent vibration resistance. This product description is an automated translation of the original Finnish description.
O-ring seals ensure venting and sealing in distribution boxes and housings. For example, in OBO's tested O-ring seal V-TEC, the sealing surface achieves enclosure rating IP 68 thanks to OBO's special molding technology. Its venting and sealing have been tested according to DIN EN 50262. Optimal thread adaptation to the correct rise ensures excellent vibration resistance. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Cable gland (EC000441)
Thread typeMetric
Nominal thread size metric/PG12
Pitch thread1.5 mm
Thread length8 mm
Wrench width15 mm
Hexagon angular dimension16.5 mm
Suitable for cable diameter3.5-7 mm
MaterialPlastic
Material qualityPolyamide (PA)
Surface protectionUntreated
Halogen freeyes
Glass-fibre reinforcedno
Degree of protection (IP)IP68
Shock resistantno
ColourGrey
Product codes
SAPABO425
STK1711112
PLC1711112
GTIN/EAN4012195533177
Manufacturer part number2022862
Vendor material number2022862
Basic information
Package measurements (L x W x H)29 x 16 x 16 mm
Package volume0.007 l
Package weight0.003 kg
Base uniteach
Package units1 / 50 / 500 / 50000
Package contents–
UNSPSC39121311
BrandOBO BETTERMANN
VendorOBO BETTERMANN OY
