CABLE GLAND V-TEC13, PK13,5 RAL7035
Product code
1711013
Cable gland PG13,5, PA, Light grey, 7035
Usage
V-TEC VM gland seals from OBO are ideal for quick and convenient sealing and strain relief in distribution boxes and other enclosures. Thanks to the sealing lip and OBO’s special lamella technology, protection class IP 68 is achieved. Strain relief and sealing have been tested according to DIN EN 50262. Threads are metric or PK threads, allowing easy installation anywhere. Once installed, the gland seal lasts almost indefinitely: the optimal adaptation of the thread to the correct rise ensures permanent vibration resistance. Applications: from distribution boxes in single-family homes to industrial distribution cabinets. Operating temperature range: -20°C to +65°C This product description is an automated translation of the original Finnish description.
V-TEC VM gland seals from OBO are ideal for quick and convenient sealing and strain relief in distribution boxes and other enclosures. Thanks to the sealing lip and OBO’s special lamella technology, protection class IP 68 is achieved. Strain relief and sealing have been tested according to DIN EN 50262. Threads are metric or PK threads, allowing easy installation anywhere. Once installed, the gland seal lasts almost indefinitely: the optimal adaptation of the thread to the correct rise ensures permanent vibration resistance. Applications: from distribution boxes in single-family homes to industrial distribution cabinets. Operating temperature range: -20°C to +65°C This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Cable gland (EC000441)
Thread typePG
Nominal thread size metric/PG13.5
Pitch thread1.5 mm
Thread length9 mm
Wrench width24 mm
Hexagon angular dimension27 mm
Suitable for cable diameter5-12 mm
MaterialPlastic
Material qualityPolyamide (PA)
Surface protectionUntreated
Halogen freeyes
Glass-fibre reinforcedno
Degree of protection (IP)IP68
Shock resistantno
ColourGrey
Product codes
SAPABO418
STK1711013
PLC1711013
GTIN/EAN4012195446958
Manufacturer part number2024748
Vendor material number2024748
Basic information
Package measurements (L x W x H)38 x 22 x 25 mm
Package volume0.021 l
Package weight0.01 kg
Base uniteach
Package units1 / 50 / 400 / 12800
Package contents–
UNSPSC39121311
BrandOBO BETTERMANN
VendorOBO BETTERMANN OY
The country of origin stated by the supplierFinland
