FEEDING TRUNKING LKM60060RW,60X60X2000 STEEL
Product code
1418648
Cable trunking with floor knock-outs 60x60x2000, St, Strip galvanised/powder-coated, Pure white, 9010
LKM steel installation channel with lid
Steel installation channels LKM are suitable for cable installations anywhere mechanical stresses occur. They are also suitable for installing fire-resistant cables and provide excellent EMC shielding as steel channels. Thanks to the complete range of sizes from 20 x 20 mm to 60 x 200 mm and practical mounting accessories, there are appropriately sized installation channels for every application area. Cable clips can be attached to the LKM steel installation channel to facilitate cable installation. Potential equalization continuity as well as the connection between the cover and base is achieved without wires. Available hot-dip galvanized and powder-coated in pure white. This product description is an automated translation of the original Finnish description.
Steel installation channels LKM are suitable for cable installations anywhere mechanical stresses occur. They are also suitable for installing fire-resistant cables and provide excellent EMC shielding as steel channels. Thanks to the complete range of sizes from 20 x 20 mm to 60 x 200 mm and practical mounting accessories, there are appropriately sized installation channels for every application area. Cable clips can be attached to the LKM steel installation channel to facilitate cable installation. Potential equalization continuity as well as the connection between the cover and base is achieved without wires. Available hot-dip galvanized and powder-coated in pure white. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Mini/maxi trunking (EC000059)
Height63.7 mm
Width60 mm
Length2000 mm
Usable cross section3153 mm²
MaterialSteel
Material qualityOther
Halogen freeno
Anti-bacterial treatmentno
Surface protectionContinuously galvanised and coated
Suitable for circuit integrityno
ColourWhite
RAL-number9010
Number of permanent partitions0
Number of plug-in partitions0
Type of fasteningBottom perforation
Product codes
SAPALN557
STK1418648
PLC1418648
GTIN/EAN4012196977307
Manufacturer part number6248608
Vendor material number6248608
Basic information
Package measurements (L x W x H)1000 x 85 x 145 mm
Package volume12.325 l
Package weight1.747 kg
Base unitMeter
Package units8
Package contents–
UNSPSC39131712
BrandOBO BETTERMANN
VendorOBO BETTERMANN OY
