FIRE PROOF TRUNKING OBO PLCD W090810
Product code
1418125
Fire protection duct
Fire protection ducts are used to protect cables installed in the duct from external fire and the environment from internal cable fire. The fire protection duct protects cables installed in the duct from external fire for a time according to the E classification and from the heat and smoke of internal cable fire for a time according to the I classification. OBO's fire protection ducts are environmentally friendly, lightweight concrete reinforced with glass fiber, easily workable with hand tools. The visible surfaces of the duct can be finished afterward, for example, with paint or wallpaper. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Fire-resistant duct (EC002657)
Fire resistance class according to EN 13501-2EI90
Outer height120 mm
Outer width100 mm
Inner height362 mm
Number of flame resistant sides4
Insulating materialOther
Intumescent interior liningno
SheathingOther
Surface protectionUntreated
ColourGrey
Cover attachmentScrew tight
Suitable for application central air supply and -exhaustno
Suitable for application in the exhaust gas areano
Suitable for cable protectionyes
Product codes
SAPDME832
STK1418125
PLC1418125
GTIN/EAN4012196836512
Manufacturer part number7215834
Vendor material number7215834
Basic information
Package measurements (L x W x H)367 x 105 x 125 mm
Package volume4.817 l
Package weight2.101 kg
Base uniteach
Package units1 / 5 / 160
Package contents–
UNSPSC39131713
BrandOBO BETTERMANN
VendorOBO BETTERMANN OY
