OBO BETTERMANN
SURGE ARRESTER HOUSEHOLD OBO V10-C 3+NPE+FS
Product code
3228536
No product description available.
Product details
Technical specifications
Product class (ETIM)Surge protection device for power supply systems (EC000941)
System configuration TNyes
System configuration TN-Cno
System configuration TN-C-Syes
System configuration TN-Syes
System configuration TTyes
Number of conductors (without earthing)4
Nominal discharge surge current (8/20)10 kA
Max. discharge surge current (8/20)20 kA
Nominal voltage AC230 V
Nominal voltage DC230 V
Max. continuous voltage AC280 V
Voltage protection level1.1 kV
Max. overcurrent protection device, parallel connection (fuse)125 A
Integrated short-circuit protectionno
Integrated backup fuseno
Product codes
SAPCNA938
STK3228536
PLC3228536
GTIN/EAN4012195363941
Manufacturer part number5094931
Vendor material number5094931
Basic information
Package measurements (L x W x H)92 x 73 x 68 mm
Package volume0.457 l
Package weight0.379 kg
Base uniteach
Package units1 / 24 / 1152
Package contents–
UNSPSC39121621
BrandOBO BETTERMANN
VendorOBO BETTERMANN OY
