COMBI BOX ONNKOMB 32A 5P6H 400V IP44
Product code
2441672
The Onnline power connectors product family includes basic power plugs, extension sockets, and surface-mounted power sockets. The range also includes phase-change plugs and combination sockets.
All Onnline power connectors are equipped with screw connections. Their enclosure rating is IP44, inductance 5P6H, and rated voltage 400V. The power plug and extension socket feature a quick locking system (turn & fix) for connecting components. There is also a new screwless cable strain relief for cable penetration. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Panel-mounted CEE socket outlet (IEC 60309) (EC001317)
IEC-amperage32 A
Voltage according to EN 60309-2400 V (50+60 Hz) red
Number of poles5
Clock hour position6 h
Identification colourRed
Degree of protection (IP)IP44
Connection systemScrewed terminal
Insert directionStraight
Product codes
SAPAJJ993
STK2441672
PLC2441672
GTIN/EAN6410024416727
Basic information
Package measurements (L x W x H)185 x 80 x 140 mm
Package volume2.072 l
Package weight0.498 kg
Base uniteach
Package units1 / 7
Package contents–
UNSPSC39121308
BrandONNLINE
VendorONNINEN OY
