POWER EXTENTION ONNLINE OBPR 125A 5P6H 400V IP67
Product code
2441612
New addition to the Online power connectors product family; extension sockets 63A and 125A with IP67 enclosure rating and nominal voltage of 400V.
The power plugs and extension sockets feature a quick locking system (turn & fix) for connecting components. There is also a new screwless cable strain relief for cable entry. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)CEE socket outlet (IEC 60309) (EC001321)
IEC-amperage125 A
Number of poles5
Voltage according to EN 60309-2400 V (50+60 Hz) red
Clock hour position6 h
Identification colourRed
Degree of protection (IP)IP67
Connection systemScrewed terminal
Cable entryGland nut
MaterialPlastic
Surface treatment contactsOther
Military modelno
Product codes
SAPCLE946
STK2441612
PLC2441612
GTIN/EAN6410024416123
Basic information
Package measurements (L x W x H)287 x 124 x 124 mm
Package volume4.413 l
Package weight1.34 kg
Base uniteach
Package units1 / 2 / 20 / 160
Package contents–
UNSPSC39121308
BrandONNLINE
VendorONNINEN OY
