POWER SOCKET OUTLET OBPR 32A 5-NAP 6H 400V IP44

Product code
2441670
The Onnline power connectors product family includes basic power plugs, extension sockets, and surface-mounted power sockets. The range also includes phase-change plugs and combination sockets. All Onnline power connectors are equipped with screw connections. Their enclosure rating is IP44, inductance 5P6H, and rated voltage 400V. The power plug and extension socket feature a quick locking system (turn & fix) for connecting components. There is also a new screwless cable strain relief for cable penetration. This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)CEE socket outlet (IEC 60309) (EC001321)
IEC-amperage32 A
Number of poles5
Voltage according to EN 60309-2400 V (50+60 Hz) red
Clock hour position6 h
Identification colourRed
Degree of protection (IP)IP44

Product codes

SAPAJJ991
STK2441670
PLC2441670
GTIN/EAN6410024416703

Basic information

Package measurements (L x W x H)160 x 85 x 110 mm
Package volume1.496 l
Package weight0.318 kg
Base uniteach
Package units1 / 10 / 60 / 400 / 800
Package contents
UNSPSC39121308
BrandONNLINE
VendorONNINEN OY

Environment and safety

Manufacturer

NameOnninen Oy
Postal addressTyöpajankatu 12, 00580 Helsinki
