POWER SOCKET-OUTLET ONNLINE OBPR 125A 5P6H 400V IP67
Product code
2441614
Online surface-mounted power socket 125A 5-pole 400V IP67. Screw-type connectors in the socket. One cable entry at the top and bottom of the enclosure and two at the bottom. The range also includes an equivalent 63A version. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)CEE socket outlet (IEC 60309) (EC001321)
IEC-amperage125 A
Number of poles5
Voltage according to EN 60309-2400 V (50+60 Hz) red
Clock hour position6 h
Identification colourRed
RAL-number3000
Degree of protection (IP)IP67
Connection systemScrewed terminal
Cable entryAnti-kink sleeve
MaterialPlastic
Type of fasteningExternal mounting
Insulated mountingyes
Military modelno
Product codes
SAPCLF328
STK2441614
PLC2441614
GTIN/EAN6410024416147
Basic information
Package measurements (L x W x H)395 x 190 x 225 mm
Package volume16.886 l
Package weight1.93 kg
Base uniteach
Package units1 / 12 / 21 / 84
Package contents–
UNSPSC39121308
BrandONNLINE
VendorONNINEN OY
