LIGHT STRIP OPAL BASIC IP65/44 230V 8W/M 4000K 25M
Product code
DMQ599
The LED strip's enclosure rating is IP65, making it suitable for humid indoor and outdoor environments. The strip can be easily and quickly installed directly into a socket plug (enclosure rating IP44) with a 1.5-meter rubber cable connection (H05RN-F 1.0 mm²).
The LED strip can be cut at marked intervals every meter, and only a qualified electrician is permitted to cut the LED strip. Before cutting the strip, disconnect the plug from the socket. Use a suitable moisture-resistant silicone or adhesive for attaching the end cap to ensure the required enclosure rating (IP65) is maintained.
Features
- Power max. 200 W, 8 W/m
- Luminous flux 800 lm/m
- Color temperature 4000 K
- Supply voltage 230 V AC 50/60 Hz
- Service life 15,000 hours
- LED strip length 25 m, width 11.5 mm, height 5.5 mm
- Enclosure rating IP65 (strip) and IP44 (plug)
Product details
Technical specifications
Product class (ETIM)Light ribbon/-hose/-strip (EC002706)
ModelStrip
Mounting methodSurface mounting
Lamp typeLED not exchangeable
Lamp power per meter8 W
Luminous flux per meter800 lm
Luminaire efficacy100 lm/W
Voltage typeAC
Type of power supplyMains power supply
Lamp voltage230 - 230 V
Beam angle120 °
Type of control gearNot required
Suitable for dimmerno
Exchangeable control gearno
Energy efficiency class of the light source according to EU regulation 2019/2015F
Rated lifetime L70/B50 at 25 °C15000 h
Product codes
SAPDMQ599
PLCDMQ599
GTIN/EAN6438056408237
Basic information
Package measurements (L x W x H)250 x 250 x 110 mm
Package volume6.875 l
Package weight2.85 kg
Base uniteach
Package units1 / 4 / 4 / 96
Package contents–
UNSPSC39112102
BrandOPAL
VendorONNINEN OY
Documents (3)
Images
Brochures & documents
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)37.05
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000490
