FILTER ABE1P STARTER SET SWISS AIR SERIES
Product code
6313732
Gas filter upgrade pack for the Swiss Air respirator model. Replaces the standard TH3 filter and its cover. Includes: ABE1P combination filter, spark arrestor, 50 pieces of pre-filter MIA, and ABE1P filter protective cover.
Typical application areas:
Painting, lacquering, impregnation, coating, repair of painted surfaces, gluing, spraying and handling of solvents and pesticides, dismantling of microbial-damaged structures, metal industry, welding, construction and maintenance of roads, pavements, and roofs (bitumen handling), dust, welding fumes, microorganisms such as bacteria and viruses, etc. Popular model in shipbuilding and automotive industry as well as in construction.
Explanation of filter type markings:
A: Filters organic gases and vapors with a boiling point >65 °C. Brown color on the filter side.
B: Filters inorganic gases and vapors with a boiling point >65 °C (excluding carbon monoxide). Gray color on the filter side.
E: Filters sulfur dioxide and other corrosive gases and vapors. Yellow color on the filter side.
1: Low gas concentration, below 1000 ppm (=1000 ml/m³).
P: Highest particle filtration class for dust, mist, and vapor containing microorganisms such as bacteria and viruses, gypsum, wood or textile fibers, marble, titanium dioxide, volcanic rock, rock wool, cleaning agents, oil, spices, salt, feed, etc. Protects against dust that can cause lung diseases, such as cotton, graphite, kaolin, zinc, and aluminum. Also protects against hazardous dust caused by coal, asbestos (always check specific dismantling instructions), bauxite, quartz, and iron ore. Also protects against toxic dust caused by manganese, lead, and chromium.
As a preliminary note: This set will also be compatible with future launch of A2 and ABEK filters. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Filter for breathing mask (EC002941)
Construction typeOther
Connection typeOther
Standard threadOther
Housing materialPlastic
Protects against organic vapouryes
Protects against acid gasyes
Protects against ammoniano
Protects against methylamineyes
Protects against formaldehydeyes
Protects against mercuryno
Protects against chlorineyes
Protects against particulatesyes
Protects against hydrogen chlorideyes
Protects against sulfur dioxideyes
Protects against hydrogen sulfideyes
Product codes
SAPDLY149
STK6313732
PLC6313732
GTIN/EAN7640429872838
Manufacturer part number4088.455
Vendor material number4088.455
Basic information
Package measurements (L x W x H)260 x 30 x 160 mm
Package volume1.25 l
Package weight0.13 kg
Base uniteach
Package units1
Package contents–
UNSPSC46182007
BrandOPTREL
VendorVANDERNET OY
