KITCHEN MIXER ORAS 1030FS-104 SAFIRA ECO

Oras Safira 1030FS-104 is a kitchen faucet with a swivel spout of 120° (can be limited to 40°–80°). A flow restrictor (3.4 l/min) enables low water consumption. The faucet meets the requirements for efficient water use set by Green Building. The faucet features flexible supply hoses.

Features

• spout type: fixed aerator
• connection type: flexible supply hoses
• lever/handle type: single operating lever/handle with hot/cold symbols
• mechanical parts: ř 40 mm control unit
• special features: inner body made of zinc-resistant brass, 3S-Installation mounting system
• spout type: swivel spout with angle limitation capability, profile structure
• color: chrome
• temperature controls: possibility to limit temperature and flow rate
• flow rate at 300 kPa (with flow restrictor): 0.056 l/s
• connection size: G3/8
• hot water: max. +70 °C
• material: brass
• projection: 213 mm
• operating pressure: 50–1000 kPa
• noise class: I (ISO 3822)

Replacement Parts

• operating lever: LVI 6420625
• protective cap: LVI 6420632
• locking nut: LVI 6420331
• control unit, Green Building: LVI 6420733
• control unit: LVI 6420301
• spout, L=210: LVI 6510259
• spout restrictor, 40°–80°: LVI 6420574
• spout restrictor, 120°: LVI 6420642
• mounting screw, M8x1, L=130: LVI 6420637
• mounting kit: LVI 6420634
• aerator, M24x1, -104: LVI 6420700
• aerator, M24x1, -105: LVI 6510075
• aerator, M24x1 STD HC B: LVI 6421620
• bearing ring: LVI 6420620
• X-sealing pack: LVI 6420263
• bearing ring: LVI 6420348
• base gasket: LVI 6420646
• support plate, 100x60 mm: LVI 6420134

This product description is an automated translation of the original Finnish description.
