KITCHEN MIXER ORAS 1038F-104 SAFIRA ECO

Kitchen faucet with a swivel, high spout 120° (can be limited to 0° or 60°). Flow restrictor (3.4 l/min) enables low water consumption. The faucet meets the requirements for efficient water use set by Green Building. Flexible supply hoses. Features

• connection type: flexible supply hoses
• lever/handle type: single lever/handle, hot/cold symbols
• mechanical parts: ř 40 mm control cartridge
• special features: 3S-Installation mounting system
• spout type: swivel spout with angle limitation capability
• color: chrome
• temperature controls: temperature and flow rate limitation capability
• flow rate at 300 kPa (with flow restrictor): 0.054 l/s
• pressure loss at flow rate (0.2 l/s) with flow limiter: 240 kPa
• connection size: G3/8
• DN size (standard size): DN8
• hot water: max. +70 °C
• material: brass
• projection: 178 mm
• operating pressure: 50 - 1000 kPa
• noise class: I (ISO 3822)

Replacement Parts

• aerator, M22x1: LVI 6421610
• spout: LVI 6420394
• spout angle limiter, 60°/0°: LVI 6420240
• spout angle limiter, 120°: LVI 6420287
• spout angle limiter, 60°/0°: LVI 6420169
• sealing kit: LVI 6420144
• lever: LVI 6420625
• cover cap: LVI 6420632
• locking nut: LVI 6420331
• control cartridge: LVI 6420301
• base seal: LVI 6420646
• mounting plate, 100x60 mm: LVI 6420134
• mounting screw, M8x1, L=130: LVI 6420637
• mounting kit: LVI 6420634

This product description is an automated translation of the original Finnish description.
