KITCHEN MIXER ORAS 2734FHN-33 OPTIMA STYLE DWV 3V
Product code
6219207
Oras Optima Style 2734FHN-33 is a matte black kitchen faucet with a high, swiveling spout and an electronic dishwasher valve (connected to cold water). The spout swivel angle is 120° (can be limited to 0° or 60°). The faucet is battery-powered at 3 V and features a lever-style handle and flexible supply hoses.
Features- spout type: standard aerator
- connection type: flexible supply hoses
- dishwasher valve type: electronic dishwasher valve
- mechanical parts: ř 40 mm control unit
- spout type: swiveling spout
- color: matte black
- temperature controls: temperature and flow rate limitation capability
- dishwasher valve open time: 4 h / 12 h
- flow rate at 300 kPa: 0.2 l/s
- pressure loss at flow rate (0.1 l/s): 75 kPa
- pressure loss at flow rate (0.2 l/s): 300 kPa
- backflow prevention (EN1717): EB
- connection size: G3/8
- hot water: max. +70 °C
- material: brass
- operating pressure: 50 - 1000 kPa
- battery: AA 1.5 V Lithium x 2
- Bluetooth version: 5.x (D060577)
- EU directives: Radio Equipment Directive 2014/53/EU, Low Voltage Directive 2014/35/EU, EMC Directive 2014/30/EU, RoHS Directive 2011/65/EU
- EN standard: ETSI EN 301 489-1 V1.9.2, ETSI EN 300 328 v2.2.2, EN 61000-6-1:2007, EN 61000-6-3:2007+A1:2011+AC:2012, EN 60335-1:2012+A11+A13+A1+A14+A2+A15:2021, Part 19.11.4
- noise class: I (ISO 3822)
- protection class: IP 55
- aerator, STD M22x1 CC A (matte black): LVI 6420825
- aerator and wrench, M18.5x1 (chrome): LVI 6422193
- handle (matte black): LVI 6420827
- locking nut, M42x1.5, SW 38: LVI 6420331
- control unit: LVI 6420301
- limit stop, 120°: LVI 6420725
- spout seal kit: LVI 6510210
- mounting plate, 100x60 mm: LVI 6420134
- mounting plates with nuts: LVI 6420358
- control unit, 3 V, Bluetooth: LVI 6420676
- battery, 1.5 V AA Lithium: LVI 6420268
- pilot valve, 3 V: LVI 6420432
- magnetic valve diaphragm: LVI 6420750
- seal, 18.5/12x2 EPD This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Kitchen mixing tap (EC011431)
ModelMechanical
Type of gripSingle-grip
Type of electronic operating methodOther
Self-closingno
Type of temperature controlManually operated
With temperature limityes
Temperature limit retrofittableno
Material tapBrass
Surface protectionOther
Surface treatmentPolished
Basic colourOther
Accent colourOther
MountingTop/tap hole
Number of tap holes1-hole
Connection supplyHose (gland nut)
Product codes
SAPDBS147
HPAC6219207
PLC6219207
GTIN/EAN6414150102462
Manufacturer part number2734FHN-33
Vendor material number6219207
Basic information
Package measurements (L x W x H)580 x 290 x 75 mm
Package volume12.62 l
Package weight2.7 kg
Base uniteach
Package units1 / 5 / 20 / 60
Package contents–
UNSPSC30181702
BrandORAS
VendorORAS OY
Documents (10)
Environment and safety
Sustainability categories
Circular economy
Features
Availability of spare parts after discontinuation (years)10
Flow rate at 3 bar (l/min)12
Type ApprovalYes
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)20.709
GWP, uniteach
Source for GWP dataEPD
Documents (1)
Sustainability brochures & documents
