KITCHEN MIXER ORAS 3031F-81 INSPERA BRONZ DWV 3 V

Oras Inspera Comfort+ 3031F-81 is a kitchen faucet with a side lever, smart dishwasher valve, and a tall, swiveling, pull-out spout with a 120° rotation (can be restricted to 60°–0°). The length of the pull-out spout is adjustable. The dishwasher valve automatically closes after 4 or 12 hours (one press keeps the valve open for 4 hours, a five-second press keeps it open for 12 hours). Battery-powered, 3 V. Flexible connection hoses. Finish: brushed bronze.

• connection type: flexible connection hoses
• dishwasher valve type: electronic dishwasher valve
• electronic components: magnetic valve, separate control unit, indicator lights for functions, low battery indicator
• lever/handle type: single operating lever/handle with hot/cold symbols
• mechanical components: ř 40 mm control unit, debris filters
• spray functions: 2 spray functions
• spout type: swiveling spout, pull-out, rotation angle restriction possible
• color: brushed bronze
• temperature controls: temperature and flow rate restriction possible
• dishwasher valve open time: 4 h / 12 h
• flow rate at 300 kPa: 0.16 l/s
• pressure loss at flow rate (0.2 l/s): 490 kPa (70% qv = 240 kPa)
• connection size: G3/8
• warm water: max. +70 °C
• material: brass
• projection: 231 mm
• operating pressure: 50 - 1000 kPa
• battery: AA 1.5 V Lithium x 2
• Bluetooth version: 5.x (D060577)
• EU directives: Radio Equipment Directive 2014/53/EU, Low Voltage Directive 2014/35/EU, EMC Directive 2014/30/EU, RoHS Directive 2011/65/EU
• EN standard: EN 817, EN 15091, ETSI EN 301 489-1 V1.9.2, ETSI EN 300 328 v2.2.2, EN 61000-6-1:2007, EN 61000-6-3:2007+A1:2011+AC:2012, EN 60335-1:2012+A11+A13+A1+A14+A2+A15:2021, Part 19.11.4
• sound class: I (ISO 3822)
• protection class: IP 55

• aerator (chrome): LVI 6510238
• spray hose, L=1500, G1/2-M14x1: LVI 6510255
• spout restrictor, 60°/0°: LVI 6420615
• locking nut: LVI 6420331
• control unit: LVI 6420669
• mounting kit: LVI 6420651
• support plate, 100x60 mm: LVI 6420134
• flexible connection hose, L=550, G3/8-M10x1 LH: LVI 6420672
• debris filters: LVI 6420722
• seal, 18.5/12x2 EP This product description is an automated translation of the original Finnish description.
