KITCHEN MIXER ORAS 3035F-81 INSPERA BRONZ DWV 3 V
Product code
6219196
Oras Inspera 3035F-81 is a brushed bronze-colored kitchen faucet with an intelligent dishwasher valve and a high, swiveling spout with 120° rotation (can be limited to 0° or 60°). The dishwasher valve automatically closes after 4 or 12 hours (one press keeps the valve open for 4 hours, a five-second press keeps it open for 12 hours). Battery-powered, 3 V. Flexible connection hoses.
Features- spout type: standard aerator
- connection type: flexible connection hoses
- dishwasher valve type: electronic dishwasher valve
- electronic components: magnetic valve, separate control unit, indicator lights for functions, low battery indicator
- lever/handle type: single operating lever/handle with hot/cold symbols
- mechanical components: ř 40 mm control unit
- special features: 3S-Installation mounting system
- spout type: swiveling spout with rotation angle limitation capability
- color: brushed bronze
- temperature controls: temperature and flow rate limitation capability
- dishwasher valve open time: 4 h / 12 h
- flow rate at 300 kPa: 0.2 l/s
- pressure loss at flow rate (0.2 l/s): 300 kPa
- backflow prevention (EN1717): AA
- connection size: G3/8
- warm water: max. +70 °C
- material: brass
- projection: 219 mm
- operating pressure: 50 - 1000 kPa
- battery: AA 1.5 V Lithium x 2
- Bluetooth version: 5.x (D060577)
- EU directives: Radio Equipment Directive 2014/53/EU, Low Voltage Directive 2014/35/EU, EMC Directive 2014/30/EU, RoHS Directive 2011/65/EU
- EN standard: ETSI EN 301 489-1 V1.9.2, ETSI EN 300 328 v2.2.2, EN 61000-6-1:2007, EN 61000-6-3:2007+A1:2011+AC:2012, EN 60335-1:2012+A11+A13+A1+A14+A2+A15:2021, Part 19.11.4
- noise class: I (ISO 3822)
- protection class: IP 55
- spout restrictor, 60°/0°: LVI 6420169
- spout restrictor, 120°: LVI 6420287
- spout sealing kit: LVI 6510210
- indicator light: LVI 6420665
- control unit: LVI 6420669
- locking nut: LVI 6420331
- base seal: LVI 6420646
- mounting plate, 100x60 mm: LVI 6420134
- mounting screw, M8x1, L=130: LVI 6420637
- mounting kit: LVI 6420634
- flexible connection hose, L=550, G3/8-M10x1 LH: LVI 6420734
- This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Kitchen mixing tap (EC011431)
ModelElectronic
Type of gripSingle-grip
Type of electronic operating methodOther
Self-closingno
Type of temperature controlManually operated
With temperature limityes
Temperature limit retrofittableno
Material tapBrass
Surface protectionOther
Surface treatmentPolished
Basic colourOther
Accent colourChrome
MountingTop/tap hole
Number of tap holes1-hole
Connection supplyHose (gland nut)
Product codes
SAPDBC555
HPAC6219196
PLC6219196
GTIN/EAN6414150103124
Manufacturer part number3035F-81
Vendor material number6219196
Basic information
Package measurements (L x W x H)628 x 294 x 84 mm
Package volume15.509 l
Package weight3.519 kg
Base uniteach
Package units1 / 6 / 18 / 36
Package contents–
UNSPSC30181702
BrandORAS
VendorORAS OY
Documents (9)
Certificates
Brochures & documents
Links
Environment and safety
Sustainability categories
Circular economy
Features
Availability of spare parts after discontinuation (years)10
Flow rate at 3 bar (l/min)12
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)26.9907
GWP, uniteach
Source for GWP dataEPD
Documents (1)
Sustainability brochures & documents
