UTILITY ROOM MIXER ORAS 1074 SAFIRA
Product code
6219125
Wall-mounted auxiliary faucet with swivel and rotating spout (200 mm).
- Base 1070, LVI code 6310828
- D-spout 211220, LVI code 6517200
- Valve 200100, LVI code 6512000
- Hose connector 223012, LVI code 6512510
- Connection type: silencers
- Valve type: pull-out valve
- Handle type: single operating lever/handle with hot/cold symbols
- Mechanical parts: Ø 40 mm control unit
- Spout type: rotating spout
- Color: chrome
- Temperature controls: temperature and flow rate limitation capability
- Flow rate at 300 kPa: 0.25 l/s
- Flow rate at 300 kPa with flow restrictor: 0.2 l/s
- Pressure loss at flow rate (0.2 l/s) with flow restrictor: 300 kPa
- Pressure loss at flow rate (0.2 l/s): 200 kPa
- Connection size: G3/4
- Hot water: max. +80 °C
- Installation width: CC150± 3 mm
- Material: brass
- Projection: 200 mm
- Operating pressure: 50 - 1000 kPa
- Noise class at 0.2 l/s: I (ISO 3822)
- Operating lever: LVI 6420625
- Protective cap: LVI 6420616
- Locking nut: LVI 6420331
- Control unit: LVI 6420301
- Connector: LVI 6421582
- Sealing kit, D24/15x4: LVI 6421662
- Valve: LVI 6421583
- Retention screw (10 pcs), M6x8: LVI 6421592
- O-ring, 13.6x2.4: LVI 6421897
- Spacer bushing (10 pcs), 18/20.6: LVI 6421614
- Retention ring (10 pcs): LVI 6421612
- Flow nozzle, M22x1: LVI 6421610
- This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Kitchen mixing tap (EC011431)
ModelMechanical
Type of gripSingle-grip
Type of electronic operating methodOther
Self-closingno
Type of temperature controlOther
With temperature limityes
Temperature limit retrofittableno
Material tapBrass
Surface protectionChromium-plated
Surface treatmentPolished
Basic colourChrome
Accent colourChrome
MountingWall
Number of tap holes1-hole
Centre distance150 mm
Product codes
SAPCDE932
HPAC6219125
PLC6219125
GTIN/EAN6414150078477
Manufacturer part number1074
Vendor material number6219125
Basic information
Package measurements (L x W x H)210 x 185 x 160 mm
Package volume6.216 l
Package weight2 kg
Base uniteach
Package units1 / 10 / 40 / 120
Package contents–
UNSPSC30181702
BrandORAS
VendorORAS OY
The country of origin stated by the supplierFinland
Documents (12)
Environment and safety
Sustainability categories
Circular economy
Features
Availability of spare parts after discontinuation (years)10
Flow rate at 3 bar (l/min)15
Type ApprovalYes
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)13.2
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000445
