UTILITY ROOM MIXER ORAS 1077 SAFIRA
Product code
6219126
Wall-mounted auxiliary faucet with a showerhead and rotating spout (250 mm).
- body 1070, LVI code 6310828
- showerhead 126004-11, LVI code 6515661
- rotating spout 211525, LVI code 6517310
- shower hose 241020-11, LVI code 6515041
- bracket 251500-11, LVI code 6515771
- connection type: silencers
- hand shower type: quick-clean/showerhead
- lever/handle type: single operating lever/handle, hot/cold symbols
- mechanical parts: Ø 40 mm control unit
- spout type: rotating spout
- color: chrome
- temperature controls: temperature and flow rate limitation capability
- flow rate at 300 kPa: 0.17 l/s
- pressure loss at flow rate (0.1 l/s): 100 kPa
- connection size: G3/4
- warm water: max. +80 °C
- installation width: CC150± 3 mm
- material: brass
- projection: 250 mm
- operating pressure: 50 - 1000 kPa
- noise class at 0.2 l/s: I (ISO 3822)
- operating lever: LVI 6420625
- protective cap: LVI 6420616
- locking nut: LVI 6420331
- control unit: LVI 6420301
- O-ring, 13.6x2.4: LVI 6421897
- spacer pin (10 pcs), 18/20.6: LVI 6421614
- retaining ring (10 pcs): LVI 6421612
- jet nozzle, M22x1: LVI 6421610
- ejector: LVI 6421609
- This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Kitchen mixing tap (EC011431)
ModelMechanical
Type of gripSingle-grip
Type of electronic operating methodOther
Self-closingno
Type of temperature controlOther
With temperature limityes
Temperature limit retrofittableno
Material tapBrass
Surface protectionChromium-plated
Surface treatmentPolished
Basic colourChrome
Accent colourChrome
MountingWall
Centre distance150 mm
Connection supplyOther
Product codes
SAPCDE929
HPAC6219126
PLC6219126
GTIN/EAN6414150078491
Manufacturer part number1077
Vendor material number6219126
Basic information
Package measurements (L x W x H)365 x 145 x 170 mm
Package volume9 l
Package weight2.04 kg
Base uniteach
Package units1 / 7 / 28 / 84
Package contents–
UNSPSC30181702
BrandORAS
VendorORAS OY
The country of origin stated by the supplierFinland
Documents (11)
Environment and safety
Sustainability categories
Circular economy
Features
Availability of spare parts after discontinuation (years)10
Flow rate at 3 bar (l/min)10.2
Type ApprovalYes
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)13.464
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000445
