TAPPING BLOCK VG02-0003
Product code
1914180
Branching platforms are used for branching and connecting copper conductors in electrical equipment and devices. The platforms are easy to install, and all models can be mounted either with screws or directly onto a DIN rail. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Feed-through terminal block (EC000897)
Connectable conductor cross section fine-strand without cable end sleeve35-240 mm²
Connectable conductor cross section fine-strand with cable end sleeve35-240 mm²
Connectable conductor cross section multi-wired35-240 mm²
Rated current In560 A
Rated voltage750 V
Type of electrical connection 1Screw connection
Mounting methodOther
Material insulation bodyThermoplastic
Operating temperature80-80 °C
ColourBlack
Product codes
SAPAMG522
STK1914180
PLC1914180
GTIN/EAN6410019141801
Manufacturer part numberVG02-0003
Vendor material number1914180
Basic information
Package measurements (L x W x H)70 x 56 x 82 mm
Package volume0.321 l
Package weight0.25 kg
Base uniteach
Package units1 / 15
Package contents–
UNSPSC43221702
BrandOUNEVA
VendorOUNEVA OY
The country of origin stated by the supplierFinland
