UNIVERSAL CONNECTOR OTL 1xAL/CU, 2,5-35mm2 GREY
Product code
1914300
OTL universal connector gray 2.5-35mm2 1xAl/Cu 500 pieces pack This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Feed-through terminal block (EC000897)
Connectable conductor cross section fine-strand without cable end sleeve2.5-25 mm²
Connectable conductor cross section fine-strand with cable end sleeve2.5-25 mm²
Connectable conductor cross section solid-core2.5-35 mm²
Connectable conductor cross section multi-wired2.5-35 mm²
Rated current In135 A
Rated voltage1000 V
Type of electrical connection 1Screw connection
Type of electrical connection 2Screw connection
Number of levels1
Number of clamp positions per level1
Suitable for conductor materialAluminium/copper
Mounting methodDIN rail (top hat rail) 35 mm
Material insulation bodyThermoplastic
Operating temperature-25-80 °C
Width16 mm
Product codes
SAPCKZ273
STK1914300
PLC1914300
GTIN/EAN6410019143003
Manufacturer part numberVC05-0197
Vendor material number1914300
Basic information
Package measurements (L x W x H)0 x 0 x 0 mm
Package volume0.036 l
Package weight0.027 kg
Base uniteach
Package units500
Package contents–
UNSPSC39121421
BrandOUNEVA
VendorOUNEVA OY
The country of origin stated by the supplierFinland
