UNIVERSAL CONNECTOR OTL 1xAL/CU, 35-240mm2 GREY
Product code
1914301
OTL universal connector gray 35-240mm² 1xAl/Cu 50 pieces pack This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Feed-through terminal block (EC000897)
Connectable conductor cross section fine-strand without cable end sleeve35-185 mm²
Connectable conductor cross section fine-strand with cable end sleeve35-185 mm²
Connectable conductor cross section solid-core35-240 mm²
Connectable conductor cross section multi-wired35-240 mm²
Rated current In425 A
Rated voltage1000 V
Type of electrical connection 1Screw connection
Type of electrical connection 2Screw connection
Number of levels1
Number of clamp positions per level1
Suitable for conductor materialAluminium/copper
Mounting methodDIN rail (top hat rail) 35 mm
Material insulation bodyThermoplastic
Operating temperature-25-80 °C
Width37 mm
Product codes
SAPCKZ278
STK1914301
PLC1914301
GTIN/EAN6410019143010
Manufacturer part numberVC05-0209
Vendor material number1914301
Basic information
Package measurements (L x W x H)0 x 0 x 0 mm
Package volume0.24 l
Package weight0.195 kg
Base uniteach
Package units50
Package contents–
UNSPSC39121421
BrandOUNEVA
VendorOUNEVA OY
The country of origin stated by the supplierFinland
Documents (7)
Images
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)0.0136
GWP, uniteach
Source for GWP dataEPD
