BATHROOM FAN PAX CALIMA, BLACK, AUTOMATIC

Product code
8040656
Pax Calima is a modern fan combining elegant design with the latest technology. Calima is characterized by extremely quiet operation, high efficiency, and low energy consumption. A fully automatic fan that can be adjusted via a mobile app when desired. Suitable for all spaces where air needs to be removed, not just bathrooms. Also suitable for boats and motorhomes (alternative 12 V). With factory settings, Pax Calima is a fully automatic exhaust fan that does not necessarily need any adjustment. It runs continuously at a low base speed, ensuring constant air exchange. In addition to three speed settings, Calima features a Boost rapid ventilation mode. The fan’s base operation automatically intensifies when the light sensor is activated or when humidity rises rapidly and significantly, for example due to showering. If you wish to adjust and control Calima, it is done via Bluetooth using a smartphone or tablet. Pax Calima is extremely easy to install and use. Cleaning the fan has been made even easier and requires no tools. It is approved for installation in humid environments. Calima can be installed in ducts with a diameter of 100–140 mm. Installation in smaller or larger ducts is possible using Pax cover plates or an extension frame. The fan operates continuously at base air exchange (approximately 30 m³/h). If the sensor detects a change in light or movement in the room, the fan’s power increases (approximately 60 m³/h). If humidity rises rapidly and significantly, for example during showering, the power increases further (approximately 95 m³/h). When humidity has been removed, the fan returns to base air exchange (approximately 30 m³/h). If you want additional features or to adjust air volumes, download Pax Wireless. It allows programming of calendar functions and use of enhanced ventilation or automatic modes. For more information on using the Pax Wireless app, visit the manufacturer’s website at paxsuomi.fi. The app also enables pairing the fan with an exhaust towel dryer equipped with Pax’s Momento II™ timer, so Calima automatically activates the towel dryer when room humidity rises. Alternative 12 V: Pax Calima has been developed for various applications. The built-in 12-volt input enables operation, for example, in a summer cottage, boat, or motorhome. The fan consumes very little power, so it does not drain the battery. Available in either white or matte black. Five-year warranty. Calima features
  • fully automatic, adjustments via app
  • 17-20 dB (A) at 3 m
  • 110 m³/h free airflow
  • energy consumption max. 4 W
  • boost or enhanced operation mode
  • separate 12 V input.
This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Ventilator for in-house bathrooms and kitchens (EC001141)
Nominal width177 mm
Volume flow110 m³/h
ColourBlack
Medium temperature0.0 - 50.0 °C
Mounting methodSurface mounted
Rated voltage230 V
Mains frequency50 Hz
Assembly arrangementOther
Nominal current0.046 A
Rotational speed2400 1/min
Housing materialPlastic
DirectionAxial
Degree of protection (IP)IP44
Noise emission20 dB(A) re 1 pW
With connection setno

Product codes

SAPCLW219
HPAC8040656
STK8510094
PLC8040656
GTIN/EAN7391477153010
Manufacturer part number1530-1
Vendor material number1530-1

Basic information

Package measurements (L x W x H)195 x 190 x 90 mm
Package volume3.33 l
Package weight0.58 kg
Base uniteach
Package units1 / 4 / 240
Package contents
UNSPSC42272219
BrandPAX
VendorVOLUTION SWEDEN AB

Environment and safety

Features

HumidistatYes
Power (W)4
Occupancy sensorYes
emissions calculated according to EN 15821:2010Yes
