Fan PAX 1860-1

Light sensor and humidity sensor, backdraft damper. Pax Passad 31 (a model with similar features to Passad 30 but with a backdraft damper*) is installed in a duct without natural draft (directly through an exterior wall). The fan starts automatically from the adjustable light sensor or when the room humidity exceeds the set value. The fan can also be turned on manually via a separate light/power switch with or without a 15-minute after-run time. Low energy consumption, durable (ball bearings), 5-year warranty. * Note! The backdraft damper must not be used in a gravity ventilation duct (e.g., in the ceiling), as air exchange must not be prevented! Features

• Humidity sensor
• Light sensor with after-run time
• Manual operation via separate switch with or without 15-minute after-run time.

Installation

• Own duct Ř100 or Ř125 mm
• Duct without natural draft (directly through an exterior wall).

Additional accessories

• Maintenance switch (No. 8510193)
• Installation plate (No. 8080655)
• Mounting frame (No. 8510195)
• Wall pipes 2 pcs (No. 8510484)
• Exterior grille white (No. 8510481).

This product description is an automated translation of the original Finnish description.
